City Bus

Dimensions

Length (mm) 12000 Width(mm) 2550 Height (mm) 3150 Wheelbase (mm) 6100 Gross Vehicle Weight (kg) 18000 Curb Weight (kg) 12000 Seats 35+1

Engine

Power 290 HP, 6 cylinder Displacement (L) 8.9 Torque (Nm) 1050

Transmission

Transmission Automatic gearbox with retarder

Chassis

Fuel tank (L) 200 Suspension Air suspension Front axle Front disc axle Rear Axle Rear disc axle; Axle ratio: 5.22 Braking Dual-circuit service fully dry braking system, WABCO EBS Steering Power steering Body structure Monocoque body structure A/C 32000 kCal/h Battery (V) 24 Doors 2

Dimension (LxWxH) (mm)	12000 × 2550 × 3150
Gross Weight (kgs)	18000
Speed(km/h)	95
Turning radius	<21m
Wheel base	6100
Seats	35+1
No. of doors	2

Engine	290 HP, 6 cylinder, 8.9L, 1050Nm@1000-1900rpm
Transmission	Automatic transmission
Suspension system	Electronically Controlled Air Suspension (ECAS), including kneeling function
Axle	Front and Rear disc axle
Brake system	Front and rear disc brakes, With EBS
Steering System	Power steering
Air conditioner (A/C)	Roof mounted, brushless fan, Dependent, with 32,000 Kcal/hr
Fuel tank	200 liters with anti-siphon fuel filling system
Electrical System	CAN System with OBD II diagnostic
Information system	Passenger Announcement system with GPS Multi-color LED destination board
Facility for disabled	Wheel chair docking in the passenger compartment Manual ramp at entrance

Engine Compartment	Automatic Fire Suppression System Smog Detection system
Battery Compartment	Smog Detection system
Wheels	Wheel Temperature label Wheel Nut Lug Tire Pressure monitoring system (TPMS)
Others	Neutral when bus stops CCTV Emergency escape roof hatch

Vehicle Tracking	Telematics
Others	Three Beacon lamps on the roof top Micro switch for opening door
